User Manual
Overview
The LINDY USB 3.0 to 2x SATA Drive Clone Adapter can be used as
both an external dual HDD SATA adapter and a HDD clone adapter.
The HDD Cloning function should be used standalone and creates a bit
by bit clone of the source HDD onto the target HDD.
The HDD Docking function can be used when connected via
SuperSpeed USB 3.0, allowing easy data transfer and superior transfer
rates up to 5Gbps between the computer and HDDs, especially when
transferring large volumes of data.
Features
• Connects 2 SATA HDDs to a computer using a single connector
• Accepts 2.5/3.5" HDD with 22 pin SATA combo interface. For Micro
and Slim SATA and IDE drives, adapters and adapter cables are
available from LINDY separately.
• Computer connection via USB 3.0
• Supports SATA 1.5/3.0Gbps speed
• Compatible
with Windows
(32/64bit), Linux Kernel 2.6.31 and above (drivers included, native
support)
Package Contents
1x USB 3.0 to 2x SATA Drive Clone Adapter with integrated USB
3.0 cable type A
1x Power Supply 100-240VAC / 5V & 12V DC
1x Power Cord
1x This Manual
Clone Adapter
English
Deutsch
Français
Italiano
English
XP/Vista/7/Server2003/Server
Bottom Source
LED
Source
Clone Button
USB Cable
Installation and Use
• Connect the power supply
• If you want to clone HDDs we suggest not to connect the SATA
Clone Adapter to your computer
• For normal operation connect the SATA Clone Adapter to your
computer by USB 3.0 cable
• Connect the HDDs to the SATA Clone Adapter. The Operating
System should now detect the hard drives and make them available.
• HDDs may need to be partitioned / formatted using your operating
system disk management utility before you can access them.
• Before unplugging HDDs make sure data transfer processes are
completed.
Using the Clone Function
• Connect the source and target HDDs into the appropriate port: when
the source HDD is connected to the source port, the bottom blue
LED turns on; when the target HDD is connected to the target port,
the upper blue LED turns on.
• The target HDD must be of equal or larger capacity than the source
2007
HDD
• Make sure target HDD is empty and not partitioned
• Press the "Clone Button" and hold it for 5 seconds. Then the "Upper
Target LED" starts flashing, indicating the clone progress.
• When the clone function is finished, the "Upper Target LED" will stop
blinking, but stay on. The "Bottom LED" will turn off.
• Do not switch or unplug the HDDs during this process!
Upper Target LED
Power Input
Target
