Tune Spurtreu Gebrauchsanleitung Seite 5

Attention! Please carefully read the entire user manual before using the Spurtreu.
We congratulate you to the purchase of your Tune product. You have made a good choice. Tune products are
designed and manufactured in Germany according to highest quality standards. Nevertheless, it is necessary to
follow following advice and service the Tune product according to this user manual. Please make any other
Usage :
The Tool Spurtreu is designed for common combinations of handlebar and stem. It might be that the usage of
the Tune Tool Spurtreu is not possible for some specific handlebars or stems.
Contents:
baseplate Tune Tool Spurtreu
•
laser pointer (laser class 2) with three 1,5V LR44 button cell
•
setscrew M3x3
•
Attention :
The Spurtreu Tool is assembled from an aluminium baseplate and a laser pointer of laser class 2.
•
Never look directly into the light beam!
Specifications of the laser:
Do not use the Spurtreu Tool while riding!
•
Caution! The laserpointer of the Tune Tool Spurtreu is correctly adjusted at factory. Although the position of
the laserpointer in relation to the baseplate may change, e.g. due to battery change, falling or release of the
setscrew. Hereby a new alignment of the laserpointer may be necessary. From time to time you should check
whether the Spurtreu is still correctly aligned and make a new alignment if necessary. Therefore follow these
instructions:
The following tools are necessary: A piece of carton or something similar, a felt-pen, a plane base (e.g. a table
or a bench), a ruler, a 1,5mm allen key
1. For the alignment a horizontal line in a distance of 35mm to the plane base is needed. For example you
can make a line in a distance of 35mm to the edge of a carton (see figure 1-2).
2. Put the Tune Tool Spurtreu on the plane base in a distance of about 1m to the marked carton as shown
in figure 3.
3. Release the setscrew of the Spurtreu so that the laserpointer can be turned (see figure 4).
4. Activate the laser and turn the laserpointer in relation to the Spurtreu baseplate until the laser points at
the marked line (see figure 3).
5. Tighten the setscrew in a way that the laserpointer cannot be turned anymore.
Tune Spurtreu
manual
as of june 2014
users familiar with this manual.
wavelength: 630-680 nm
max. output power <1 mW
laser class 2
EN 60825-1:2007
