Controls and connectors

Source
Press to change between
Digital radio, FM, iPod,
and Auxiliary input
On/Standby
Telescopic
Aerial
Power adapter socket
Connector for supplied
mains power adapter
Favourites
Press and repeat to
browse through your
favourite stations
LCD display
Bass port
Headphone socket
3.5mm stereo
headphone socket
Mute
Volume down
Aux In socket
Analogue stereo
input for iPod/
MP3 player
Volume up
iPod/iPhone/iPad
dock
Press right hand
end of the front
panel to release
the iPod dock
Remote control holder
Storage recess for
remote control
USB socket
USB connector for
software upgrades
(mini-B type)
EN
3
