Technical documentation

1. Application area

The filter Maxi is used for the mechanical cleaning of the
rainwater inflow for rainwater plants, seepage plants and
ponds.
The width of the mesh (0.9 mms), assures a very fine
filtering
The maximum connectable surface (roof, terrace) is
approximately 350 m². The basic filter contains a cover
which is suitable for the installation in public
thoroughfares of the class A (cyclist, pedestrian). The
installation in areas with higher traffic loads (passenger
car, truck) is also possible.
Contents
1. Application Area
2. Operating mode, connection possibilities/pre-mounting
3. Operation/servicing
4. Main dimensions
5. Installation, general notes
5.1 Installation walkable version
5.2 Installation version drivable for cars
5.3 Installation version drivable for lorries
Important notice:
The contents of this technical documentation and corresponding manuals are a
component of the guarantee terms
Vorfilter Maxi/Prefilter Maxi DORW3106 14.01.2010
Side
6
7
7
8
9
9
10
10
6/12
