General
This attractive Princess New Classics
Fresh Juicer is one of the products in our
New Classics range, all of which are
finished in sturdy chrome-plated steel. Your
Juicer presses citrus fruits rapidly, yielding
delicious fruit juice.
The two pressing cones supplied with the
Juicer enable you to press both large and
small citrus fruit with the greatest of ease.
This handy appliance also has an
adjustable spout and a non-drip valve that
seals the juice reservoir and prevents
drips. You can use the slide on the exterior
of the appliance to increase or decrease
the size of the juice outlet and adjust the
amount of pulp in the fruit juice to your
wishes. Connect the appliance to a 220 -
240 V mains power supply.
Operation and
controls
See Figure 1.
The appliance is equipped with the
following features:
1 Housing
2 Slide
3 Lid
4 Juice reservoir with non-drip valve
5 Pulp filter
6 Pulp container (adjustable)
7 Small pressing cone
8 Large pressing cone
9 Spout
10 Power cord and plug
Before use for the first time
1 Take the appliance out of the
packaging.
2 Clean the appliance. See 'Cleaning and
maintenance'.
Fitting the parts
1 Fit the juice reservoir in the housing.
2 Fit the pulp container to the juice
reservoir.
3 Fit the pulp filter onto the shaft of the
pulp container. Turn the filter clockwise
or anticlockwise whilst pushing it
downwards. The filter must click into
place on the shaft.
4 See Figure 2. Make sure that the pulp
filter's plastic handle (2) is securely
attached to the projecting lug (1) on the
slide; otherwise the filter will not work
properly.
5 Move the slide to increase or decrease
the size of the openings in the pulp
container and adjust the amount of pulp
in the fruit juice.
6 Fit the small pressing cone into the
opening in the pulp container. This is
used to press small citrus fruits (such
as lemons).
7 Fit the larger pressing cone over the
smaller cone. The large pressing cone
is used to press larger citrus fruits (such
as grapefruit).
8 Dismantle the parts in the reverse
sequence.
Pressing juice
See Figure 3.
1 Place a glass or container under the
spout. Lower the spout.
2 Cut a citrus fruit into halves.
3 Place the cut surface of one half on the
pressing cone.
4 Press the fruit onto the pressing cone.
The juicer will switch on and extract the
fruit juice.
5 Continue until you have pressed the
required quantity of fruit.
