Cleaning And Care - NEFF D 4644 Gebrauchsanleitung Und Montageanleitung

Filters and maintenance
Activated carbon filter:
For filtering odours during circulating-air
mode.
The activated carbon filter is installed above
the grease filter(s) in the extractor hood.
1. Remove the grease filter(s) (see Filters
and maintenance).
2. Insert the two enclosed plastic holders
into the right and left sides of the
extractor-hood housing and attach each
holder with a screw (required only if
installing an activated carbon filter for the
first time).
3. Insert the activated carbon filter from
below into the extractor-hood housing
and lock into position on both sides.
Ensure that the edge of the
activated carbon filter is underneath.
4. Re-install the grease filter (see Filters and
maintenance).
2.
3.
20
1.
Removal:
The activated carbon filter is removed in
reverse sequence.
Press the locking hooks outwards.
Replacing the activated carbon filter:
During normal operation (1 to 2 hours daily),
the activated carbon filter should be
replaced approx. 1 x year. The activated
carbon filter can be obtained from
specialist retailers (see Optional
accessories).
To ensure the best possible results,
use only original filters.
Disposal of the old activated carbon
filter:
Activated carbon filters do NOT contain
any pollutants, i.e. they can be disposed
of as household rubbish.

Cleaning and care

For appliances with a glass plate in the
pull-out vapour extractor:
The glass plate is easily removed and
can be cleaned in a dishwasher.
To remove the lugs, push outwards.
