Wall Mounted Sink Installation Instructions Anleitung für die Waschtisch-Installation These installation instructions broadly apply to following models: Diese Installation ist für folgende Waschtisch-Modelle: WT-01, WT-02, WT-03, WT-04, WT-05, WT-06S, WT-06M, WT-06L, WT-06XL, WT-06XXL...
Seite 2
Part list: Installation tools: Notes: Inhalt:: Was Sie benötigen: Anmerkungen: 1. During Installation please avoid placing tools on the sink basin to avoid damage to the surface. / Legen Sie während der Installation kein Werkzeug auf das Becken. Dies könnte die Ober äche beschädigen. 2.
Seite 3
Before you begin please evaluate the material of the wall that this sink basin will be installed on. If this is to be installed on a wall with wooden or metal studs it is imperative that a header board installed for the added support of this wash basin. / Schauen Sie sich bitte genau die Bescha enheit und die Traglast der Wand an, an der Sie den Waschtisch installieren möchten.
Seite 4
If you are mounting a faucet to the basin drill the faucet Draw a center line on the wall in reference to the center holes with a spade bit (35mm) / Wenn Sie einen Wasser- of the sink basin. / Zeichnen Sie eine Mittellinie an die Wand hahn in das Becken montieren möchten, bohren Sie die ausgehend von der Mitte des Waschtisches.
Seite 5
Mark the location of the mounting holes on the wall in Mark the height position on the wall. / reference to the holes on the basin. / Legen Sie die Waschtischhöhe fest. Markieren Sie die Bohrlöcher des Waschtisches an der Wand. Bracket / Halterung Mark below mounting hole position / Unter den Befestigungsbohrungen markieren...
Seite 6
Insert the expansion anchor into the holes and screw the lag bolt screws into the expansion anchors. / Drill the holes (12mm) / Setzen Sie die Dübel in die Löcher und drehen Sie die Bohren Sie die Löcher (12mm) Ankerbolzen in die Dübel.
Seite 7
Slide the washbasin onto the wall brackets and tighten the nuts. / Attach to wall brackets to the wall. / Schieben Sie den Waschtisch auf die Wandhalterung und Bringen Sie nun die Wandhalterung an. befestigen Sie diese.
Seite 8
Screw the basin onto the wall brackets. / Befestigen Sie den Waschtisch mit den Schrauben.
