Hettich Lift Advanced HS Montageanleitung Seite 7

sEt pEr alu 19 MM Lift Advanced HK
SET FOR ALU 19 MM
#9079603
SET 19 MM ALU
SET POUR ALU 19 MM
JUEGO PARA ALU 19 MM
# 9079709 : 1 set
55
M4 x 10
11 MIN
A - 4.5
5.2
B + 162
24
B + 162
Ø 8
Ø 8
24
24
Ø 8
4
45°
A - 4.5
Alu 19 mm
7
