ACA Current (Clamp-on 50Hz / 60Hz)
Range
40.00, 400.0, 600 A
Overload Protections :
ACD-10 Plus:
ACD-10 TRMS-PLUS:
1)
Max Induced error from adjacent current carrying conductor: 0.05 A
2)
Specified accuracy is from 1% to 100% of range and for measurements made at
the jaw center. When the conductor is not positioned at the jaw center, position
errors introduced are: Add 2% to specified accuracy for measurements made
BEYOND jaw marking lines (toward jaw opening)
3)
Add 8 digits to specified accuracy @ reading < 10% of range
OHMS
Range
400.0 Ω
4.000, 40.00, 400.0 kΩ
4.000 MΩ
40.00 MΩ
Open Circuit Voltage :
Transient protection :
Accuracy
1) 2) 3)
±( 1.5% + 8 digits)
ACA Clamp-on jaws : 600 A rms continuous
Average Sensing
True RMS sensing - 10 % to 100 % of range
Accuracy
±( 0.8% + 8 digits)
±( 0.6% + 4 digits)
±( 1.0% + 4 digits)
±( 2.0% + 4 digits)
0.4 VDC typical
6.5 kV (1.2/50μs surge)
12
