POINT OF
IMPACT ADJUSTMENT

POINT OF IMPACT ADJUSTMENT

First, unscrew the screw caps of the FALKE 1-8x24 turrets.
In principle, the following applies to all FALKE rifle scopes:
Turn the elevation and windage adjustment in or against the direction of the arrow markings on
the turrets.
In case of a high shot: Adjustment in the direction of the arrow marked "UP"
In case of a low shot: Adjustment against the direction of the arrow marked "UP"
In case of a left shot: Adjustment in the direction of the arrow marked "L"
In case of a right shot: Adjustment against the direction of the arrow marked "L"
26
RESETTING
ELEVATION AND WINDAGE
1-8x24

RESETTING ELEVATION AND WINDAGE

After the rifle scope has been adjusted, the turrets marked with lines can again be set "to zero".
Pull the elevation adjustment up slightly to unlock it.
You can now position the zero marking at the center line of the turret.
When you release the elevation adjustment it engages at that position and can now be used as a
quick-set dial.
Repeat these steps for the windage adjustment dial.
1-8x24
