DIOPTER ADJUSTMENT
APPLICATION
Application:
First, tighten the eyepiece firmly in a clockwise direction.
Then, unscrew it in the opposite direction until you can first align the marked dot with the "0" for
the first time.
This is the zero position, from where you can focus the reticle individually for your required
shooting range.
Turning clockwise: Adjustment to the "–" diopter range.
Turning anti-clockwise: Adjustment to the "+" diopter range.
26
POINT OF
IMPACT ADJUSTMENT
5-30x56

POINT OF IMPACT ADJUSTMENT

By pulling out the turrets about 2–3 mm, you unlock them; by pushing them in again, you safeguard
the turrets of the FALKE 5-30x56 against unintentional turning.
In principle, the following applies to all FALKE rifle scopes:
Turn the elevation and windage adjustment in or against the direction of the arrow markings on
the turrets.
In case of a high shot:
In case of a low shot:
In case of a left shot:
In case of a right shot:
Adjustment in the direction of the arrow marked "UP"
Adjustment against the direction of the arrow marked "UP"
Adjustment in the direction of the arrow marked "R"
Adjustment against the direction of the arrow marked "R"
5-30x56
