DESCRIPTION

ELECTRICITY SUPPLY

230V 3-phase power supply, for trimig 305-4S DV 230-400V:
this device is pre-built in 400V three-phase. If your electrical installation is in 220V 3-phase, you have
to modify the connection on the terminal board. This modification has to be realized by a competent
person.

DEVICE PRESENTATION

⑤
⑥
SEMI-AUTOMATIC WELDING FOR STEEL / STAINLESS STEEL (MAG MODE)
you should use a torch with a 1mm contact tip
SEMI-AUTOMATIC WELDING FOR ALUMINIUM (MIG MODE)
Do not cut the sheath near the connector!
