6. Installation
L
Display
10
Below picture shows a block diagram of the battery charger:
Auxiliary outputs board
Main outputs board
Power and control board
Daughter
Board
Temperature sensor
It is recommended to install a fuse (with low resistance) between the battery charger and
the battery!
Battery
outp
ut 9
outp
ut 8
outp
ut 7
outp
ut 6
outp
ut 5
outp
ut 4
outp
ut 3
outp
ut 2
outp
ut 1
alarm o
output
