3. CONTROL PANEL AND SETTING MENUS

ACCESSING THE MENUS

The push rotary encoder (3) allows the user both to perform a selection by turning it and to confirm a selection by
pressing it. These operations allow to navigate the menus and sub-menus available on the OLED display (2). Inside
the menus and sub-menus, turning the encoder to the right or to the left also allows to increase or decrease the
selected values.
The initial screen at switch-off displays the IG4T level and gain. All settings can be protected by a password.
• Once manually performed, the settings remain stored even after the speaker has
been switched off.
• After approximately one minute has elapsed since the last selection or
confirmation, the system returns to the initial screen (IG4T level/gain). The user
can also return to the initial screen from any point, in 2 ways:
a.
b.
• If the speakers are 2 and installed in a stacked configuration, the system detects
them and automatically assigns the control of both to the amplifier which is being
operated. This allows to perform an adjustment that will apply and can be stored
for the whole system, irrespective of the rotary that is being operated (mirroring
OLED) .
At switch-on, the IG4T display shows the initial screen, indicating the GAIN and the signal level,
simulating a VU METER.
INGENIA IG4T
52
CONFIRM
by selecting and confirming, when existing in a sub-menu, the symbol
by holding the push rotary encoder pressed for a few seconds
SELECT / DECREASE
Push rotary encoder use examples
English
SELECT / INCREASE
Cod. 420120235 REV. 1.2
