TROUBLESHOOTING

TROUBLESHOOTING
If a fault occurs, first check the points listed below before taking the unit for repair.If you are unable to
solve a problem by following these tips, consult your dealer or authorized service center.
WARNING: Under no circumstances should you try to repair the unit yourself.
PROBLEM POSSIBLE CAUSE
GENERAL
Volume is set too low.
No sound
Earphones are connected.
Batteries exhausted.
Batteries inserted incorrectly.
Mains cable not connected.
No key function Electrostatic discharge.
RADIO
Poor reception Weak signal.
Interferences by other appliances
(TV sets, VCRs, computers, etc.).
TAPE RECORDER
Poor sound quality Head, capstan or pinch rollers
dirty.
Tab in cassette broken out.
Recording does not
work
CD/MP3
CD/MP3 dirty or damaged.
CD skips
14
SOLUTION
Adjust the volume.
Disconnect the earphones.
Change the batteries.
Observe polarity.
Connect mains cable correctly.
Disconnect mains cable for some
seconds und reconnect.
Adjust antenna:
FM: telescopic antenna.
AM: adjust unit.
Keep distance to other appliances.
Clean head, capstan and
pinch rollers.
Cover with cello tape.
Replace or clean the disc.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS
General
Power supply AC 230V~ 50Hz
Battery operation 12V (8 x UM-1/D batteries, 1.5V)
Remote control 3V (2 x UM-4/AAA batteries, 1.5V)
Power consumption 30 Watts
Power 200 Watts (PMPO)
Dimensions approx. 660 x 216 x 200 mm
Weight approx. 5,7 kg
Operating temperature +5ºC to +35ºC
Radio
Frequency band FM : 87,5MHz-108MHz
AM : 525kHz-1615kHz
LW : 160kHz-270kHz
SW : 6MHz-18MHz
Antenna FM : Telescopic antenna
AM : built-in ferrite antenna
CD-Player
Playback system Compact Disc Digital Audio System
DAC 1 Bit D/A converter with 8-times over sampling and digital filter
Cassette deck
Recording system 4 tracks, 2-channel stereo
Erase system Magnetic erase, DC Bias
Frequency range 125Hz-6300Hz
Tape speed 4.76 cm/s
Wow and flutter 0.35% WRMS (JIS)
Audio
Speaker impedance 4Ω
Earphones impedance 32Ω
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
SERVICE & SUPPORT
If the troubleshooting fails to solve your problem,
please contact our service & support hotline at:
01805 - 22 17 84 ( € 0,14 / Min. Germany only)
In case your product needs to be sent to our service
centre, please use the provided return sticker. If the return
sticker is missing, please contact the service &
support hotline.
