LOCATION OF CONTROLS
FRONT VIEW (ENLARGED DETAIL)
32 CD Stop
33 CD Play / Pause
34 LCD display
35 CD door
36 PUSH OPEN to open CD door

REAR VIEW

41 Battery compartment
42 Telescopic antenna
43 Mains power supply

REMOTE CONTROL

1 POWER
2 VOLUME UP
3 VOLUME DN
4 CD PLAY / PAUSE
5 CD SKIP / SEARCH forward
6 CD STOP
7 +10 button
8 PROGRAM
9 MODE
10 CD SKIP / SEARCH back
11 Battery compartment (rear)
6
37 CD Skip - and Search back
38 CD Skip - and Search forward
39 MODE
40 PROG Program

CONNECTIONS AND INSTALLATION

DISPLAY

1 MP3 display when playing MP3 discs
2 display in play and pause modes
3 INT. display in intro playback mode
4 REPT.1 display when repeating one track only
5 REPT. ALL display when repeating disc
6 CD display when playing a CD
7 RAN. display in random playback mode
8 PROG. display in program playback mode
9 Display current track number
CONNECTIONS AND INSTALLATION

MAINS OPERATION

The unit is designed for mains power supply 230V~50Hz but may also be operated with 8 x UM-1/D
batteries. Do not connect the unit to any other power supply to avoid damage that is not covered by
your warranty.
Connect the smaller plug to the jack at the rear of the unit and the mains plug to the wall outlet.
Disconnect from mains power supply to completely turn the unit off.

BATTERY OPERATION

Open the battery compartment, insert 8 UM-1/D batteries and close the battery compartment again.
To avoid damage, which may result from leaking batteries, remove the batteries when they become
exhausted or when the unit is not to be used for a longer period of time.
Battery operation is automatically suspended when connecting the mains power cable.

BATTERY SAFETY PRECAUTIONS

Follow the battery manufacturer's safety, usage and disposal instructions.
Only use batteries of the same type and size.
Insert the batteries observing the polarity (+/-). Failure to properly align the battery polarity can cause
personal injury and/or property damage.
Do not mix battery types (e.g. alkaline, zinc/carbon, rechargeable batteries) or exhausted and new
batteries.
Remove exhausted batteries from the device. Remove the batteries when the device will not be used for
extended periods of time to prevent damage due to rusted or corroded batteries.
To avoid fire and explosion do not recharge normal batteries.Keep batteries away from children and
pets.

PRIVATE LISTENING WITH EARPHONES

Use earphones for private listening (not supplied). Connect 3.5 mm jack to PHONE jack (6). If your
earphones come with a different jack, please purchase an appropriate adaptor. Connecting the
earphones automatically mutes the speakers.
