is also provided with an outer protection plate made of high polymer materials. The plate is
wear-resistant, thermostable, and has no dregs-sticking, thus a very long service life.
4.

MAIN SPECIFICATIONS

1.
Filter dimension
2.
View area
3.
Light shade number
4.
Dark shade number
5.
UV/IR protection
6.
Time from light to dark
7.
Time from dark to light
8.
Sensitivity/Delay
9.
Power supply
10.
Operaing temperature
11.
Warranty
12.
Grind function
13.
Optical Classifi cation
5.

METHOD OF OPERATION

1.
Assemble the mask oas shown in the constrcion and asembly fi gure (see page 5).
2.
The power supply
The power of ECLIPSE 3 Pro helmet is provided by solar cells with two lithium batteries.
Turning on or off is automatic controlled by circuit. You can use this helmet at any time
you need and take it away after working without operating any key. Using this helmet is
fully free like glas fi lter helmet.
3.
Darkness selection
Striking the arc, the observing window darkens immediately. At this moment, according
to the technical requirment, the operator adjusts the darkness knob 10 in the direction as
shown by the arrow to select the optimum darkness.
4.
Delay time selection
By moving the DELAY selector knob 12 on the rear of the cartridge, the time taken fro the
lens to lighten after welding can be altered from 0,7-0,9 second.
Turn to MIN: The time the lens lighen after welding changes to be shorter. The short-
est time is about 0,1 second depending upon welding point temperature and shade
set. This setting is ideal for track welding or production welding with short welds.
Turn to MAX: The time the lens lighen after welding changes to be longer. The longest
time is about 0,9 second depending upon welidng point tempratureand shade set. This
setting is ideal for welding at high amperage wehere there is an after glow from the weld.
5.
Sensitivity selection
By moving the SENSITIVITY selector knob 11 on the rear of the cartridge, the sensitivity
to ambient light changes can be altered.
Turn to LO: The photosensitivity changes to be lower. Sutitalbe for high am-
perage welding and welding in bright light conditions (lamp light or sun light).
Turn to HI: The pohtosensitivitty changes to be higher. Suitable for low amperage welding
and using in pool light conditions.
Suitable for using with teady arc process such as TIG welding.
If the helmet can be used normally, we suggest using this helmet with a bit high sensitivity.
6.
Becuase the shapes of man's heads vary from person to person. The work position and
the obseving angle is differnte, operator may adjust the headbandadjusting button 17 and
the segmental positioning plate 18 to select an appropriate observing angle. By pushing
and truning the adjstmetn screw 16, the perimeter of the head band can be adjusted.
7.
Welding/gringing warning function
114 x 133 x 9,5 mm
100 x 60 mm
4
9-13
up DIN 15
1/10000 s
0,1-0,9 s
adjustable stepless
solar cells & replaceable battery
-10°C - 55°C (14°F - 131°F)
two years
yes
1/1/1/2
