Blockdiagramm - dbx DriveRack Bedienungsanleitung

™
DriveRack PA
Anhang A
A.6 Blockdiagramm
Alignment Delay Alignment Delay Alignment Delay
Peak Stop Limiter Peak Stop Limiter Peak Stop Limiter
3-Band-PEQ 2-Band-PEQ 2-Band-PEQ
Crossover-Sektion - (2X3, 4,5,6)
Stereo Compressor
SubHarmonic Synth
AFS Notch Filter
RTA
Stereo/Mono Mic Preamp
Pink Noise
®
