Montage -instructie
Mounting instruction
Montageanleitung
Préscription de montage
!
IT IS IMPORTANT FOR EVERYONE'S SAFETY THAT ALL INSTRUCTIONS ARE FOLLOWED.
RETAIN THESE INSTRUCTIONS.
Conditions for installation
• This screen is intended for interior use.
• Requires a single phase electricity supply 230 V / 50 Hz + earth. Corresponds to standards CE EN 60335-1 and EN 60336-2-97:
- Class 1 electric motor, fi tted with a ground wire to be connected to earth during installation (supply cable).
- Supply cable inside the motor with no connection under the case.
- Electrically isolated case from the motor by the mounting system.
• Do not cut the motor cable to less than 10 cm in length.
!
Do not remove the anti-fall safety brackets located under each end of the roler tube.
Conditions for use
• Designed for optimum usage between 15°C and 25°C and maximum humidity of 80%.
• Must be kept away from sources of heat (as these may cause fabric deformation) and protected from splashes of water, steam, dust,
smoke or any other hazards that may damage the equipment.
• This class of screen is designed to be used intermittently, in other words, a few times each day.
• The motor is equipped with a thermal circuit breaker with automatic resetting. It is designed to function continuously for 4 mn.
Beyond this, it will stop in order to cool down.
Caution: automatic resetting: for safety, reset reverse to stop position beforehand.
Fixing the screen
• Fix fi rmly the brackets with screws of nature and length appropriated to material constituting the wall or the ceiling (see the table for
the weight of the screen ). (B1 or C1)
Note : other mounting modes than the standard brackets can be used (Contact Projecta.).
• Do not place them further than one meter from each end (see
• Mount using screws and hardware suited to the type of wall or ceiling : see
• Ensure that the screen is kept horizontal (max. variation of 3 mm per m ).
• Remove (or half-open) the end plates of the casing for sliding the heads of the screws into the T-grooves. (
• Fixing to the wall (see B)
- Slide the treaded plates into the rear T-grooves of the casing (B3) than screw the end plates back (B4).
- Raise the screen on the level of the brackets (B6), introduce the screws and washers into the brackets, take in place the
spacers on the screws (B5) and screw these screws into the threaded plates (B7 and B8) by tightening them correctly.
• Fixing behind a beam :
• Fixing to the ceiling (see C).
- Slide the threaded plates into the upper T-grooves of the casing (C3) than screw the end plates back (C4).
- Raise the screen on the level of the brackets (C5), introduce the screws and washers into the brackets and screws these
screws into the threaded plates (C6) by tightening them correctly.
Electrical connection (See D)
• 3 position switch ( up – stop – down )
Caution: never wire in 2 switches in order to obtain 2 control points.
Note: other control systems can be used (consult Projecta).

Operation

• The limit switches have been pre-set at the factory. Incorrect use could void the guarantee.
If you notice that
• The screen is not moving: check the electrical connection.
• The screen will come down but does not have enough power to retract and/or makes an unusual noise : check the electrical
connection. It is possible that the 2 motor wires (up and down = black and brown wires) are connected simultaneously (should be
avoided at all costs as there is the risk of damaging the motor).
• The screen stops or fails to function after several operations: the motor, which is designed for intermittent use (maximum 4 to 5 mn
in a row) has reached its maximum temperature and the thermal safety function has cut in: wait a few minutes for it to cool down.
• If in doubt, contact your dealer.
Projecta reserves the right to modify its products in order to make technical improvements.
www.projectascreens.com
G S
IANT CREEN
as with the wall but by using the front T-grooves of the casing.
Disposizioni di montaggio
Explicación de la instalación
Инструкция по монтажу
E
LECTROL
A)
B or C. It is essential to check that the fi xings are secure.
B2 or C2).
