18 | English

Functional Description

Intended Use
The saw stand is intended to accommodate the
following stationary saws from Bosch (as of
2010.03):
– GCM 8 S 3 601 L16 0..
– GCM 800 S 3 601 L16 1..
– GCM 10 0 601 B20 0..
– GCM 10 J 3 601 M20 2..
GCM 10 M
– GCM 10 S 0 601 B20 5..
– GCM 10 SD 0 601 B22 5..
– GCM 12 0 601 B21 0..
– GCM 12 SD 0 601 B23 5..
– GTM 12 3 601 M15 0..
Selected chop and mitre saws from other man-
ufacturers can also be mounted.
Together with the power tool, the saw stand is
intended for the cutting to length of boards and
profiles.
Product Features
The numbering of the product features refers to
the illustration of the saw stand on the graphics
pages.
1 Workpiece support
2 Table extension
3 Locking knob of the table extension 2
4 Attachment set
5 Locking knob for height adjustment of the
roller stand 7
6 Locking knob of the workpiece support 1
7 Roller stand
8 Length stop
9 Height-adjustable leg
10 Carrying handle
11 Transport stop*
12 Transport wheels*
13 Height-adjustable support leg of the table
extension 2*
1 609 929 U17 | (4/8/10)
14 Socket spanner (13 mm)/
Allen key (4 mm)/Phillips screwdriver
15 Locking pin
16 Button for releasing lever 17
17 Lever for locking the attachment set
18 Movable nut
19 Fastening kit, power tool
20 Fastening kit for transport wheels*
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
Technical Data
Saw stand
Article number
Length of saw stand
without table extension
Length of saw stand
with table extension
Height of saw stand
Max. carrying capacity
(power tool + work-
piece)
without table extension
– Attachment set
Max. carrying capacity
(power tool + work-
piece)
with table extension
– Attachment set
– Per table extension
Weight, approx.
GTA 3800
Professional
3 601 M24 000
mm 1578
mm 3877
mm 824
kg 250
kg 150
kg 50
kg 22
