Technical Data:
Ledino Waterproof Fixture
„Niehl 18" + „Niehl 24"
DIN EN 60598-2-24 (D) for the use
in fi re hazardous locations
„suitable in stable" ammonia resistant
grey housing ABS, stainless steel clamps
transparent diff usor PS (polystyrol)
G13 socket for retrofi t LED tubes T8
Cascadable - prepared for series installation
IP65 - protection against jets of water
statutory warranty 2 years
11300184004023 = Niehl 18
Housing: 1265 x 72 x 86 mm, 1.26 kg
Incl. Ledino LED-LM-Niehl18:
LED tube 18 W, T8/G13, 1200 mm, glass
1800 lm , 4000 K neutral white, CRI >80
not dimmable, beam angle: 120°
energy class A+, 18 kWh/1000
lifetime: 25000 h, switch cycles 20000
Lamp housing and tube together:
1620 lumens, 1.46 kg
18 W LED light correspond to
approx. 135 W normal bulb light
11300244004023 = Niehl 24
Housing: 1565 x 72 x 86 mm, 1.66 kg
Incl. Ledino LED-LM-Niehl24:
LED tube 24 W, T8/G13, 1500 mm, glass
2400 lm , 4000 K neutral white, CRI >80
not dimmable, beam angle: 120°
energy class A+, 24 kWh/1000
lifetime: 25000 h, switch cycles 20000
Lamp housing and tube together:
2160 lumens, 1.92 kg
24 W LED light correspond to
approx. 184 W normal bulb light
Used units must not be disposed of with household waste!
If the unit is no longer operational, every consumer is required by law to dispose
of used devices separate from household waste, e. g. at a collection point run by
the communal authority borough. In this way, used devices can be recycled and
waste materials disposed of in an environmentally friendly manner.
For this reason, electrical equipment is labelled with the displayed symbol.
We hereby confi rm that the products are in line with the regulations ‒ and in
particular with the protection requirements ‒ of the European Unionʼs directive
on the harmonisation of the legislation relating to electromagnetic compability
(2014/30/EU), the low voltage directive 2014/35/EU, the directive for Energyrela-
ted Products 2009/125/EG and the RoHS directive 2011/65/EC.
Ledino
Deutschland GmbH
the energy saving company
8
D
IP65
Spitzahornweg 1
14974 Ludwigsfelde/ Berlin
Germany
Ledino
LED LIGHTING
the energy saving company
Bedienungsanleitung
11300184004023 = Niehl 18 (18 W, 1620 lm, 1265 mm, 4000K)
11300244004023 = Niehl 24 (24 W, 2160 lm, 1565 mm, 4000K)
Hohe Energieeinsparung • Energieklasse A+ • Lange Lebensdauer
Geringe Wärmeabstrahlung • 100 % Licht sofort • Quecksilberfrei
LED-Feuchtraumleuchte
Stall geeignet
Niehl 18/ Niehl 24
