6.2.0 Place pick needle
Open the clamp screw (7) with the included Allen key.
Place the pick needle (4) into the resulting gap (5) between holder (8)
and clamp (6) and push the pick needle all the way to the stop.
Tighten the clamp screw (7) with the Allen key so that a firm hold of the
needle is ensured.
Now MULTIPICK KRONOS is operational.
6.3.0 Work with MULTIPICK KRONOS
6.3.1 Switch On and Off MULTIPICK KRONOS
9
To switch on the Multipick Kronos you activate the push button on top of the
device. As soon as you release the push button (10), Kronos turns off.
6.3.2 Adjust the amplitude
With the adjustment screw (9) on top of the device you may adjust the amplitude
deflexion in a range of 1 – 4 mm while operating. Thanks to the pressure spring
the adjustment screw is held at the adjusted position.
4 5 6 7 8
10
6
