Safety Instructions; Operating Instructions En - IKA 35 648 00 Betriebsanleitung

Contens
EN

Safety instructions

Correct use
Unpacking
Factory settings
Installation
Operating modes
Setting the HI-TEMP
Adjusting the set-point temperature
Replacing extension cable and sensor
Error messages
Accessories
Technical data
Safety instructions
W W a a r r n n i i n n g g : : The supply voltage (Limited Power Supply) for the ETS-
D5 m m u u s s t t be provided via a safety/isolation transformer that com-
plies with D D I I N N E E N N I I E E C C 6 6 1 1 5 5 5 5 8 8 .
Note: This equipment must only be used with media that have a
flash point higher than the temperature safety limit set for the
magnet agitator and/or heating system used.
The equipment must not be operated in areas where there is a risk
of explosion.
The stainless steel temperature sensor must not be used with
aggressive media such as acids, caustic solutions or distilled
water, due to the risk of corrosion. The H66 glass sensor should
be used in such cases.
Please ensure that the spiral cable does not come into contact
with the heating plate.
Take care when touching the temperature sensor!
ETSD5 0306
Burn hazard! The temperature sensor may heat up to 450°C
when inserted in the media!
Page
Please observe all accident prevention regulations applicable to
the activity and the work station. Personal protective equipment
9
should be worn when operating the equipment.
10
10 Danger:
The user must check that all conditions have been met for the safe
10
and correct operation of the equipment before operating the IKA-
10
11 TRON ® ETS-D5 with a heater that does have a DIN 12878 compli-
11 ant connector, and therefore does not provide cut-out proection.
(The cut-out protection is a mechanism that ensures that the elec-
11
11 trical heating circuit is switched off should the contact thermome-
12 ter (ETS-D5) be broken or if the connector is removed.).
12
H+P magnetic agitator systems (no break fuse protection
12
included)
When the supply current for the ETS-D5 is interrupted, the elec-
tronics for the heatable magnetic agitator system will take over
the temperature control. This means that the magnetic agitator
system will heat up to the temperature set (e.g. 300 °C). Readjust
the set-point temperature for the magnetic agitator system or
switch the heating off.
Danger when using flammable media with a low boiling
temperature.
Corning Magnetic Agitator PC-400, PC-420, PC-600, PC-620
When using the ETS-D5 in conjunction with a Corning Magnetic
Agitator it is absolutely essential that the rotary "heat" dial on the
magnetic agitator is set to the "O" (off) position. The ETS-D5 will
only control the set temperature when it is in this position.
Warning: The heating plate temperature limiter is not active in this
operating mode.
If the rotary "heat" dial on the magnetic agitator is not in the "O"
position then the magnetic agitator will heat up to the temperatu-
re set, regardless of the settings on the ETS-D5.
Warning: ETS-D5 is inactive.
9
