S = Default, L = Loco address, S = Switch address, LS = Loco and switch address usable
CV Description
49 MD configuration
Bit
0
1
2
3
4
5
6
7
116 Servo wait time
117 Switch position right
118 Switch position left
119 SW1 command allocation
120 SW1 address high
121 SW1 address low
122 SW1 speed value
123 SW1 time for automatic switch
back function
124 SW1 staytime
hold time after reach end
position
125 A1 command allocation
126 A1 dimming value
127 A1 address high
128 A1 address low
129 A1 time for special function
*SWD PLUG please set CV49 Bit 2 = 1 (inverted on) by signals!
Value
0 – 28
+64
+128
25
S L/S
0* LS
Value
1 SW1 no defined position
2 SW1 def. position „straight"
4 SW1 normal output
8 SW1 don't hold endposition
16 A1 normal output
32 A1 normal function
64 A1 normal function
128 A1 normal function
10 LS
255 LS
0 LS
1 L
0 S
1 S
10 LS
0 LS
0 LS
2 L
100 LS
0 S
2 S
2 LS
ATTACHMENT 1 – Command allocation
Application
0 = Switch with light key
1 – 28 = Switch with F-key
permanent off
permanent on
Range
bitwise programming (add value)
OFF (Value 0)
1 – 20
0 – 255 Change only, if switch cannot turn correctly!
0 – 255
see attachment 1, active if CV 29 Bit 7 = 0
1 – 2048
0 – 255 Speed value 1 ms each value
0 – 255
1 – 255 = time base 0,25 sec. each value
0 – 255
1 – 255 = time base 0,1 sec. each value
important, when drives peed is small
see attachment 1, active if CV 29 Bit 7 = 0
1 – 100 dimming value in % (1 % ca. 0,2 V)
1 – 2048
1 – 255
Note
ON
SW1 defined position
SW1 def. position „turned"
SW1 inverted output
SW1 hold endposition
A1 inverted output
A1 heart polarisation
A1 flashes while switching
A1 flashes with defined pos.
1 – 10 Digitalservo
10 – 20 Analogservo
active if CV 29 Bit 7 = 1
active if CV 29 Bit 7 = 1
0 = off
0 = off
active if CV 29 Bit 7 = 1
active if CV 29 Bit 7 = 1
time base (0,1s / value)
Note
Not for SW1
Not for SW1
