Connecting The Single Parts; Connecting - Fixpoint 45268 Betriebsanleitung

4.3

Connecting the single parts

Tab. 11: Connecting the single parts
Fig. 16: Connecting the single parts - putting on
Fig. 17: Connecting the single parts - adjusting
4.4

Connecting

Fig. 18: Connecting
Fig. 19: Connecting
End of installing. To remove, proceed in reversed order.
Risk of injury by tripping and falling
>> Place, transport and install product, parts and acceo-
ries in a safe way.
1.
W hen adjusting the LED Magnifying lamp,
a lways make sure that the connection to the
t able clamp is only plugged.
2.
Risk of life by electric shock
>>
Avoid contact with mains voltages!
>> Only use in dry ambience!
Connect the LED Magnifying lamp to a
mains socket.
Plug the LED Magnifying lamp onto
the table clamp.
Adjust the locking screw at the
upper side of the LED magnifying
lamp as needed.
