Installation
TB 3
Follow the steps to install the HDMI
4k monitor installation
Step 1: Connecting graphics splitter Thunderbolt™ 3 cable to graphics
source, such as a Desktop or Notebook PC Thunderbolt™ 3 output
interface.
Step 2: Connecting graphics splitter HDMI
Maximum connection: 2 different types of HDMI
Step 3: Power on PC and monitors. Select monitors to correct input
source.
Step 4: Change the display to clone mode, change the output display
resolution on your computer.It is recommended to use the same size,
type and resolution monitors for connecting. Same type monitor means
the monitors have the same native resolution and display refresh rate.
After installation, you will see the same image on all monitors (clone
mode) or a single image spread across multiple monitors. To change the
display setting, simply change the graphic card output resolution via the
display properties page.
NOTE: Display resolution with 2 connected 4k monitors up to
3840x2160@60 Hz each
Manual IB-SPL1026-TB3
graphics splitter.
®
output to monitor.
®
HDMI
HDMI
monitors.
®
