WACKER Group RT 820 Handbuch Seite 45

RT 820
Ref. Part No. Qty. Description
Pos. Artikel Nr. St. Beschreibung
Fitting
24 0088342 2
Verschraubung
O-Ring
25 0080734 2
O-Ring
Fitting
26 0078816 2
Verschraubung
O-Ring
27 0080731 2
O-Ring
O-Ring
28 0080736 2
O-Ring
O-Ring
29 0083970 2
O-Ring
Check valve
30 0083042 1
Rückschlagventil
Lockwasher
31 0025647 4
Federring
Fitting
33 0081583 6
Verschraubung
O-Ring
34 0080732 6
O-Ring
O-Ring
35 0080737 6
O-Ring
Fitting
36 0087067 8
Verschraubung
O-Ring
36 0087337 8
O-Ring
Fitting
37 0087068 4
Verschraubung
O-Ring
37 0087338 4
O-Ring
O-Ring
38 0080735 1
O-Ring
Valve
39 0083927 1
Ventil
Plate
40 0086504 1
Platte
Plug (threaded)
41 0052947 2
Schraubverschluß
O-Ring
42 0080733 1
O-Ring
Kit-retaining plate
43 0110913 1
Lagerplatte kpl.
0007652 - 104
Descripción
Description
Unión
Raccord
Anillo-O
Joint torique
Unión
Raccord
Anillo-O
Joint torique
Anillo-O
Joint torique
Anillo-O
Joint torique
Válvula checadora
Clapet de non-retour
Arandela elástica
Rondelle de ressort
Unión
Raccord
Anillo-O
Joint torique
Anillo-O
Joint torique
Unión
Raccord
Anillo-O
Joint torique
Unión
Raccord
Anillo-O
Joint torique
Anillo-O
Joint torique
Válvula
Soupape
Placa
Plaque
Tapón roscado
Bouchon
Anillo-O
Joint torique
Placa de retención compl.
Plaque d'arrêt compl.
41
Manifold Assembly
Verteiler Komplett
Tubo Múltiple
Tubulure
Measurem./Abm. Norm
Sealant
Torque/Drehm.
Schmierstoff
62Nm/45ft.lbs
0,924 x 0,116
24Nm/17ft.lbs
0,468 x 0,078
0,364 x 0,070
0,926 ID x
0,070in
1/4in
No.8
46Nm/33ft.lbs
0,644 x 0,087
0,489 x 0,070
24Nm/17ft.lbs
34Nm/25ft.lbs
1,171 x 0,116
34Nm/25ft.lbs
46Nm/33ft.lbs
0,755 x 0,097
