DEAR CUSTOMER,
We congratulate you on acquiring this MAC AUDIO Car HiFi Product.
Please read these instructions carefully so as to ensure optimum and disturbance-free
functioning of the appliance. Technical modifications reserved.
IMPORTANT INFORMATION TO BE HEEDED BEFORE INSTALLATION
· This device is only suitable for connection to a 12-volt system with negative earth.
· Ensure that the input cables are far enough away from the power supply cables, as this can
otherwise lead to interference. This also applies to the connecting cable for the remote control
for regulating the volume. This cable should not be laid on the side of the power supply leads but
together with the audio cable.
· Make sure that the fuse and controls are accessible after installation.
· The performance and reliability of the system depends on the quality of the installation. The
system should therefore be installed by a professional where several speakers or a complex
multi-channel system are involved.
POSITIONING AND SECURING THE SUBWOOFER
Place the subwoofer in a position where adequate ventilation of the amplifier module is guaranteed.
Make sure it rests on an even surface. The cone should not be placed directly against the car's
interior walls.
Make sure that the subwoofer is secured in such a way that it cannot slip or slide.
Screw the active subwoofer to the vehicle by using the supplied mounting bracket.
When securing the active subwoofer in place please make sure you do not damage any
vehicle cables, fuel lines, vacuum hoses or other such components.
Damage resulting from sudden changes in speed (e.g. hard braking) is not covered under the
terms of our guarantee. Use the securing device supplied for this purpose.
CONNECTING TO THE POWER SUPPLY (FIGURE 2/3)
Before installation: Remove the positive terminal from the car battery first in order to avoid
Standard car wiring is normally not sufficient for the power requirement of the integrated amplifier.
Make sure that the wiring to the earth and +12V is of the correct gauge. 6 mm² cable is the minimum
requirement for the connection from the battery to the amplifier terminals (for long cable runs over
4 meters, 10 mm² gauge cable should be used).
First make the connection between the amplifier's earth terminal (14) and the negative terminal
on the battery. To ensure a good connection, any residual dirt should first be carefully removed
from the battery terminals. A loose connection can result in malfunction or interference noise and
distortions.
A power cable with an integrated fuse is then connected between the +12V (13) terminal on the
amplifier and the battery's positive terminal. The integrated fuse should be positioned not more
than 60 cm away from the car battery. This is only to be inserted once all the installation work,
including the connecting of the speakers, has been completed.
Now connect the car radio's +12v remote control cable (P-con, Power Antenna, or similar) to the REM
(12) control socket on the amplifier. A 0.75 mm² gauge cable is sufficient for this REMOTE connection.
The REMOTE input is not connected if the active subwoofer is controlled using the loudspeaker
output of a car radio, i.e. in the case of high-level control of the active subwoofer.
short circuiting.
