B E D I E N U N G S A N L E I T U N G Beachten Sie alle Hinweise vor Inbetriebnahme! M O D E D ´ E M P L O I Lire toutes les instructions avant l´usage! U S E R M A N U A L Read full instructions before use! S o l a r m o d u l 1 5 W / 2 5 W...
Elektrozaungerätes von Frühjahr bis Herbst ausgelegt. Ein Zurückschalten des Gerätes auf eine niedrigere Leistungsstufe ermöglicht den nachladungsfreien Betrieb bis in den Winter hinein. Technische Daten: 15 Watt: Typ: SP 12/15/36 • max. Leistung: 15 W • U : 17,3 V / I : 0,86 A • U...
Seite 3
Markieren Sie die Bohrlöcher an der Bohren Sie die beiden Löcher Schieben Sie jeweils zwei Schrauben Stirnseite der MaxiBox. (Bohrerdurchmesser 5,5 mm). (M6x16) oben und unten in das Siehe auch vorherige Abbildung Aluprofilrahmen des Solarmoduls. Richten Sie die Schrauben mittig auf dem Abb.
Données techniques : 15 watts: type : SP 12/15/36. puissance max: 15 W • U charge : 17,3 V/l charge : 0,86 A. U circuit ouvert : 21,5 V/l court-circuit : 0,96 A. Dimensions (Lxl) : 568 x 243 mm. Capacité minimum de la batterie ( non comprise dans l livraison) : 80 Ah ( C100) 25 watts: type : SP 12/25/36.
Seite 5
Marquer l’emplacement du perçage sur Percer les deux trous. (diamètre du Faire glisser dans le profil en alu du le front de votre MaxiBox. Voir aussi ill. foret env. 5,5 mm) cadre du module 2 vis (M6x16) par le précédente. haut et 2 autres (M6x16) par le bas.
If the energiser is switched down to a lower power level, this maintenance-free operation can be continued throughout the winter. Technical data: 15 Watts: Type SP 12/15/36 • max. power output: 15 W • U : 17.3 V / I : 0.86 A • U 21.5 V / I...
Seite 7
Mark the drill holes on front side of Drill the holes (diameter for drill bit: Insert two screws each (M6x16) at MaxiBox (see previous picture also). approx. 5.5 mm). the top and bottom of the aluminium frame of the solar panel. Align the screws in the centre of the solar Picture of 15 W panel: Screw the mount- Picture of 25 W panel: Screw the mount-...
Seite 8
☎ PATURA KG info@patura.com • Mainblick 1 +49(0)9372-94740 www.patura.com 63925 Laudenbach • Germany Fax +49(0)9372-947429 - 8 -...
