Assembly

1 . Remove packing materials and place the
rollator walker on the floor . Insert the
front wheels in the product openings as
illustrated (see Fig . B) .
2 . Place the rollator walker upright .
Press the black release lever (9) and
open the rollator walker using the cross
bar (13) (see Fig . C, D) .
3 . Insert the sliding handles with the guide
groove facing inward into the intended
openings and secure each with a retain-
ing screw (see Fig . E, F) . Be sure the
white arrows are positioned as illustrated .
Also refer to section „Adjusting the hand-
le height" .

Bell

Note:
The bell may be mounted on the
right or left side.
Mount the bell by guiding the ratcheting
strap through the opening . Remove the bell
by pulling the release lever (G1) and remo-
ving the ratcheting strap (see Fig . G) .

Cane Holder

The parts Top cane holder (4) and
Lower cane holder (6) can be moun-
ted to the right or left side of the
product. Be sure the opening of the
cane holder top (4) always faces
outward.
Slide the top cane holder (4) and lower
cane holder (6) into the guides (see Fig .
H, I, J) .

Adjusting the handle height

ATTENTION!
• Set the sliding handle on both
sides to the same height to ensure
smooth movement.
28 GB
• The sliding handles must always
lock into a hole (K1) with an audi-
ble sound <CLICK>.
• Maximum extension: only extend
to the marking. A maximum of 4
holes may be visible (see Fig. K).
• Minimum extension: the white
arrow must still be visible (see
Fig. L).
• Only unscrew the retaining screw
to the red marking.
Note:
We recommend setting the handles
to wrist height whilst standing up
with the arms at the individual's
sides.
1 . Loosen the retaining screws (10) on the
sliding handles to set to the right height
for you .
2 . Extend the sliding handles to the desired
height, then secure the retaining screws .

Brakes

1 . Before each use verify the brakes are
working properly . If this is not the case
do not repair yourself but instead consult
your speciality retailer or Product Ser-
vices .
2 . Also check the brake cables for deforma-
tion or tears .
3 . Adjustments: adjust the brake pads (M1)
so the clearance to the surface of the
wheel is approx . 2 mm .
Loosen the locknut (O1) and adjust the
brake cable (O2) with the adjusting
screw (O3) and tighten the locknut .
Secure the adjusting screw whilst tight-
ening .
Fig. N: Brake requires adjustment
Fig. O: Correct setting
