Congratulations!
With your purchase you have decided on
a high-quality product . Get to know the
product before you start to use it .
Carefully read the following instructions
for use . Use the product only as described
and only for the given areas of application .
Keep these instructions safe .
When passing the product on to a third
party, always make sure that the documen-
tation is included .
This product complies with Directive
93/42/EEC concerning medical devices .
Contents /
Parts Description (Fig. A)
1 x Shopping rollator
1 x Bell
1 x Back strap
1 x Cane holder, top
1 x Cane holder, lower
2 x Retaining screw
1 x Instructions for use
(1) Handle
(2) Bell
(3) Support handle
(4) Cane holder, top
(5) Basket
(6) Cane holder, lower
(7) Tip assist
(8) Safety lever, red
(9) Release lever, black
(10) Retaining screw
(11) Back strap
(12) Brake lever
(13) Crossbar
26 GB

Technical specifications

Max . user weight: 120kg
Max . load basket: 20kg
Max . length: approx . 820mm
Max . width: approx . 630mm
Rollator walker height:
from approx . 820 to 930mm
Folding size: approx . 520 x 630 x 915mm
Rollator walker weight: approx . 14kg
(without accessories)
Handle length: approx . 105mm
Handle width: approx . 55mm
Distance to brake lever handle:
approx . 70mm
Wheel width: approx . 32mm
Wheel diameter: approx . 200mm
Seat height: approx . 560mm
Seat depth: approx . 360mm
Seat width: approx . 430mm
Turning radius: approx . 980mm

Symbols used

Refer to instructions for use
Date of manufacture
Batch description
Manufacturer
Max . user weight
Max . load, basket
Max . width
Pushing handles height adjustment
For outdoor and indoor use
