Delete the Command Signal (House Code)

If you decide for some reason to delete the transmission command so the
floodlight will not turn on and off, follow the below mentioned steps:
1. Press the learning key for at least 3 seconds and release the key.
2. Press the learning key again for approx. 6 seconds. The LED starts
flashing and indicates that all codes are deleted.
Adjusting the Light Sensor (LUX-Regulator)
The light sensor has a photocell that detects daylight
and darkness.
Turn the LUX regulator (8) towards T, to have the
floodlight turning on the light during day. Turn the
regulator towards
only at night.
If the floodlight turns on in daylight position, turn the
regulator towards
activating during night time turn the regulator in the
opposite direction.
Please note that the manual override function – using the remote control and
the radio switch - is not impaired by the backlight adjustment. Therefore you
will always be able to switch on and off the floodlight at day and night with the
remote control and the radio switch.

Changing the Illuminant

Make sure mains power is voltage-free before changing the illuminant!
To switch off the floodlight by using a transmitter (remote control or
radio switch) is not sufficient!
Attention! The illuminant becomes hot during operation! Allow the
illuminant to cool down before replacing. Be very careful when handling
broken illuminants.
1. Lift up the mounting hinge with a small screwdriver and open the glass
cover. Do not touch the illuminant with base fingers.
2. Remove the illuminant from the sockets and insert a new one. The
floodlight can be operated with illuminates up to 300 Watts.
Cleaning
, to have the floodlight activated
. However, if the light is not
