LINE LASER PLBS 2 A1

Introduction

Congratulations on the purchase of your
new appliance. You have selected a high-
quality product. The operating instructions
are part of this product. They contain important
information about safety, usage and disposal.
Before using the product, please familiarise yourself
with all operating and safety instructions. Use the
product only as described and for the range of
applications specified. Please also pass these oper-
ating instructions on to any future owner.

Intended use

This line laser with a drill dust collector is a battery-
operated appliance that uses vacuum technology
to create a suction mounting on standard interior
wall surfaces. The appliance can be used to project
a laser line onto a wall and collect the drill dust
created when drilling a hole of up to 10 mm in
diameter. Do not use the appliance for overhead
work. Any other usage of or modification to the
appliance is deemed to be improper and carries a
significant risk of accidents. The manufacturer ac-
cepts no responsibility for damage(s) attributable
to misuse. The appliance is not intended for com-
mercial use.
│ GB │ MT
■ 12

Features

Line laser
Horizontal level
Vertical level
ON/OFF switch for line laser
Vacuum button
Battery compartment vacuum pump
Drill dust collector/cover for drill dust collector
Protective plate/drill opening
Battery compartment for line laser
Vacuum pump seal
Release (drill dust collector)
ON/OFF switch for vacuum pump
Seal (drill dust collector)
Protective cover/wall bracket
Tab/centring rib

Package contents

1 line laser PLBS 2 A1
2 x 1.5 V AA batteries
3 x 1.5 V LR44 batteries
1 set of operating instructions

Technical details

Line laser:
Laser wavelength:
Laser output:
Laser class:
Batteries:
Levels (horizontal and vertical)
Accuracy:
Drill dust collector:
Max. drill diameter:
Vacuum pump:
Battery:
650 nm
< 1 mW
2
3 x 1.5 V
, type LR44
(direct current)
0.3°
10 mm
, type AA
2 x 1.5 V
(direct current)
PLBS 2 A1
