User manual / Bedienungsanleitung
IMPORTANT!
First, select either the MC (moving coil) or MM (moving magnet) mode according to your cartridge
type, by inserting the removable jumpers into the relevant positions on the bottom of the unit (one
each for left and right channels). The subsonic-filter function can also be adjusted by inserting jum-
pers into the relevant points on the bottom of the unit: if the jumper is inserted, then the subsonic
filter is OFF. If the jumper is not inserted, then the subsonic filter is ON.
Pic. 1: View from the bottom side
The next step is to connect the ground wire of the turntable/tonearm with the
phono headphone V2
. Make sure that the gain control is set to its lowest volume before connecting
nano phono V2 / nano phono headphone V2
the
Finally, the very last thing to do is to connect the power supply to the mains and press the power
button to the "ON" position.
Pic. 2: Rear view
- Attention -
Never cover or put anything on top of the
could lead to overheating of electronic parts.
If the unit a longer time not in use, please press the button on top of the device. If the device is
not in use, disconnect it completely from the power supply by removing the main plug from the
socket.
Pic. 3: On/Off button
Made in Germany
- Setup -
to your MC/MM cartridge and preamplifier.
Nano Phono V2 / nano phono headphone V2
nano phono V2 / nano
as this
3
