Seite 2
Auf die Geltung der Allgemeinen Geschäftsbedingungen in der jeweils gültigen Fassung wird verwiesen. Kurzbeschreibung Pufferspeicher Typen SPU-1-200, SPU-2(-W)-500 bis 1500 und SPU-2-2000 bis 5000 aus Stahl S235JR (St 37-2) gefertigt. Kein Korrosionsschutz der Behälterinnenwand und des Wärmetauschers (sofern vorhanden), da Einsatz nur in geschlossenen Heizungsanlagen als Pufferspeicher für Betriebswasser zulässig.
Planungshinweise Aufstellung Der Pufferspeicher darf nur in einem frostgeschützten Raum aufgestellt werden, an- dernfalls muß bei Frostgefahr der Speicher, sowie alle wasserführenden Armaturen und Anschlußleitungen entleert werden! Eisbildung in der Anlage kann zu Leckagen und Zerstörung des Speichers führen! Der Aufstellungsort muß den notwendigen Raum für Wartung und Reparatur, sowie eine ausreichende Tragfähigkeit des Untergrundes gewährleisten! Anschluß...
Die Fühler der Regelungen vor Anbringung der Wärmedämmung montieren. Bei Speichern mit Fühlerkanälen, Fühler senkrecht einschieben. Verrohrung jedoch erst nach Montage der Wärmedämmung anbringen. Bei dem Speicher SPU-1-200 ist bereits eine Tauchhülse eingebaut. Die Wärmedämmung des SPU-1-200 besteht aus einer geschäumten PU-Hartschaum- dämmung und abnehmbaren Folienmantel.
Seite 6
Störung / Ursache / Behebung Störung Ursache Behebung Undichtigkeit am Pufferspeicher Rohranschlüsse undicht Neu eindichten Zu wenig Temperaturdifferenz am Falsche Einstellungen an der Solar- Parameter (insbesondere Ausschalttem- Solarwärmetauscher regelung peratur-Differenz) verändern Durchfluß (solarseitig) zu gering Solarkreis entlüften Verstopfungen be- heben Pumpenleistung erhöhen Wärmetauscher verschmutzt Reinigung Keine / zu wenig Entladung des...
You are referred to the validity of the General Terms and Conditions in their respective valid version. Short description Buffer type SPU-1-200, SPU-2(-W)-500 to 1500 and SPU-2-2000 to 5000 made of steel S235JR (St 37-2). No corrosion protection of the external inner reservoir wall and the heat exchanger (if existing), because application only permitted as buffer for operating water in closed heating systems.
Planning notes Installation The buffer may be installed only in a frost-protected area. Otherwise, it must be emptied in case of danger of frost. Ice formation in the system can lead to leaks and destruction of the tank! The foundation must be even and able to support weight in order to carry the weight of the tank including its water content.
Seite 11
For tanks with sensor channel insert sensor vertically is reached. An immersion sleeve is already installed in the SPU-1-200 tank. The thermal insulation of the SPU-1-200 consists of PU hard foam insulation and a removable foil jacket. Keep fire, soldering flame and/or torches away from the insulation.
Seite 12
Fault / Cause / Remedy Fault Cause Remedy Leakage at buffer Pipe connections leaking Re-seal Temperature difference to small at solar Incorrect settings on solar heat controller Change parameters (in particular control heat exchanger temperature difference) Flow (solar-side) too low Bleed solar circuit Repair blockages Increase pump power Heat exchanger dirty...
Rimangono valide le condizioni generali nella versione attualmente in vigore. Descrizione breve Bollitore ausiliario tipo SPU-1-200, SPU-2(-W)-500 fino a 1500 e SPU-2-2000 fino a 50000 in acciaio S235JR (St 37-2). Non dispone di protezione anticorrosione sulla parete interna del serbatoio e sullo scam- biatore di calore (se presente), essendo il suo uso limitato ad impianti di riscaldamento chiusi come bollitore ausiliario per acqua sanitaria.
Indicazioni per la pianificazione Installazione Il bollitore ausiliario va installato esclusivamente in un ambiente protetto dal gelo, in caso contrario è necessario svuotarlo se sussiste il rischio di gelo. La formazione di ghiaccio nell’impianto può causare perdite e dann- eggiare il bollitore! La base di appoggio deve essere piana e resistente per poter sostenere il peso del bollitore pieno.
Seite 17
Scarico Posizionare il bollitore ausiliario in modo che possa essere svuotato il più possibile. Il bollitore SPU-1-200 è dotato di un rubinetto di carico e scarico. Attenzione: Durante lo svuotamento dell’impianto può fuoriuscire acqua bollente e causare lesioni, in particolare scottature! Sfiato Per facilitare l'operazione di sfiato, il bollitore è...
Seite 18
Guasti / causa / rimedio Guasto Causa Rimedio Perdite del bollitore ausiliario Collegamenti delle tubazioni non ermetici Ermetizzare Differenza termica troppo ridotta dello Regolazioni sbagliate della regolazione Modificare i parametri (in particolare la scambiatore di calore solare solare differenza termica di spegnimento) Portata (lato impianto solare) troppo Far sfiatare il circuito solare, disintasare ridotta...
Intercambiadores de calor solares instalados en versión con tubos lisos. SPU-1-200 y SPU-2(-W)-500 a 5000: El aislamiento se monta en la entrega. En SPU-1-200 espuma rígida de poliuretano (PU). SPU-2-2000 bis 5000: En los casos en los que el número de vainas de inmersión (existentes en el acumulador) no sean suficientes, existe la posibilidad de colocar sondas de contacto a lo largo del acumulador sobre una pletina dispuesta para ello.
Advertencias relativas a la planificación Montaje El acumulador intermedio se montará exclusivamente en una sala protegida contra heladas, de lo contrario deberá vaciarse si existe peligro de heladas! ¡La formación de hielo en la instalación puede producir escapes y romper el acumulador! La base ha de ser plana y resistente para poder soportar el peso del acumulador cargado de agua.
Seite 23
En los inter- acumuladores con canal de cables introducir la sonda en vertical hasta hacer tope. En el acumulador SPU-1-200 se encuentra ya instalado un casquillo de inmersión. El aislamiento térmico del acumulador SPU-1-200 consta de un aislamiento de espuma rígida de poliuretano (PU) y la película de recubrimiento extraible.
Seite 24
Avería / Causa / Remedio Fallo Causa Remedio Falta de estanquidad del acumulador Racores inestancos Hermetizar de nuevo intermedio Diferencia de temperatura insuficiente Ajustes incorrectos en la regulación Modificar parámetros (especialmente en el intercambiador de calor solar solar diferencia de temperatura de desconexión) Caudal (lado solar) demasiado bajo Purgar circuito solar...
Seite 25
Instructions de montage FR BE Réservoir tampon SPU-1-200, SPU-2/-W pages 25 - 30 Wolf GmbH · Postfach 1380 · 84048 Mainburg · Tel. 08751/74-0 · Fax 08751/741600 · Internet: www.wolf-heiztechnik.de Art.-Nr.: 3043757_201207 Änderungen vorbehalten!
SPU-2-W-500 à 1500: L’échangeur thermique solaire intégré est à tube lisse. SPU-1-200 und SPU-2(-W)-500 à 5000: L’isolation a été mise en place à la livraison. Pour le modèle SPU-1-200, il s’agit d’une isolation en mousse dure de PU. SPU-2-2000 bis 5000: Pour les applications pour lesquelles les doigts de gant ne suffisent pas, une barre de sondes est placée sur le chauffe-eau.
Conseils de planification Mise en place Le réservoir tampon ne peut être installé que dans un local protégé du gel. Si tel n’est pas le cas, il doit être vidangé en cas de risque de gel, ainsi que les accessoires et conduites d’eau! La formation de glace dans l’installation peut provoquer des fuites et endommager le chauffe-eau !
Un doigt de gant est déjà intégré au ballon SPU-1-200. L’isolation thermique du SPU-1-200 se compose d’une isolation en mousse dure de PU et d’une feuille de revêtement amovible. Tenir flammes, flammes à souder et chalumeaux de soudage à distance de l’isolation.
Seite 30
Pannes / Causes / Remèdes Panne Causes Remèdes Fuites au niveau du réservoir tampon Raccords de tuyaux non étanches Refaire l’étanchéité Trop petite différence de température Mauvais réglages sur le régulateur solaire Modifier les paramètres (en particulier la sur l’échangeur thermique solaire différence de température de déclenchement) Débit trop faible (côté...
Seite 31
Montagehandleiding NL BE Buffervaten SPU-1-200, SPU-2/-W Pagina 31 - 36 Wolf GmbH · Postfach 1380 · 84048 Mainburg · Tel. 08751/74-0 · Fax 08751/741600 · Internet: www.wolf-heiztechnik.de Art.-Nr.: 3043757_201207 Änderungen vorbehalten!
Er wordt verwezen naar de geldende algemene verkoopvoorwaarden in de telkenmale geldige versie. Korte beschrijving Buffervaten typen SPU-1-200, SPU-2(-W)-500 tot 1500 en SPU-2-2000 tot 5000 van staal S235JR (St 37-2) geproduceerd. Geen corrosiebescherming aan de binnenwand van het vat en de warmtewisselaar (indien aanwezig), omdat het buffervat uitsluitend in gesloten verwarmingsinstallaties voor proceswater mag worden toegepast.
Technische gegevens SPU-1 SPU-2-W SPU-2 TYPE SPU-1 SPU-2-W / SPU-2 1000 1500 2000 3000 4000 5000 Inhoud van het voorraadvat SPU-1 Liter SPU-2-W Liter 1520 SPU-2 Liter 1545 1950 2700 3950 4950 Aansluiting / Thermometer / Voelerlijst A mm Aansluiting / Thermometer / Voelerlijst B mm 1050 1135...
Seite 34
Ontwerpaanwijzingen Opstelling Het buffervat mag alleen in een vorstvrije ruimte worden opgesteld. Is dit niet het geval dan moeten bij vorstgevaar het buffervat en alle watervoerende armaturen en aansluitleidingen worden geleegd! IJsvorming in de installatie kan tot lekkages en ernstige beschadiging van het voorraadvat leiden! Het voorraadvat moet zo worden geïnstalleerd, dat voldoende ruimte voor onderhoud en reparaties beschikbaar is, bovendien moet de ondergrond over voldoende draagvermogen...
Seite 35
Leidingwerk echter pas na het aanbrengen van de isolatie monteren. Bij het voorraadvat SPU-1-200 is reeds een dompelhuls ingebouwd. De isolatie van het SPU-1-200 bestaat uit een geschuimde PU-hardschuimisolatie en een afneembare folie. Vuur, soldeervlam resp. lasbrander niet in de buurt van de isolatie brengen.
Seite 36
Storing / Oorzaak / Oplossing Storing Oorzaak Oplossing Lekkage aan het buffervat Aansluitingen van leidingen ondicht Opnieuw afdichten Te weinig temperatuurverschil aan Verkeerde instellingen op de Parameters (in het bijzonder het de warmtewisselaar die op het zonnesysteem-regeling uitschakeltemperatuurverschil) wijzigen zonnesysteem aangesloten is Debiet (zonnesysteem-zijdig) te gering Zonnecircuit ontluchten, ev.
Upozorňujeme na platnost všeobecných obchodních podmínek v aktuálním platném znění. Stručný popis Akumulační zásobník typ SPU-1-200, SPU-2(-W)-500 do 1500 a SPU-2-2000 do 5000 vyrobený z oceli S235JR (St 37-2). Není zajištěna ochrana vnitřní stěny nádrže a výměníku tepla proti korozi (pokiaľ sú k dispozícii),, protože je povoleno pouze použití...
Technické údaje SPU-1 SPU-2-W SPU-2 SPU-1 SPU-2-W / SPU-2 1000 1500 2000 3000 4000 5000 Objem zásobníku SPU-1 Ltr. SPU-2-W Ltr. 1520 SPU-2 Ltr. 1545 1950 2700 3950 4950 Připojovací hrdlo, hrdlo jímky snímače teploty A mm Připojovací hrdlo, hrdlo jímky snímače teploty B mm 1050 1135 Hrdlo pro ponorné...
Pokyny pro projektování Umístění Akumulační zásobník smí být instalován pouze v temperovaných prostorách s do- statečnou ochranou proti mrazu. Pokud nelze ochranu proti zamrznutí zajistit, musí být akumulátor i všechna hydraulicky propojená potrubí vypuštěny! Vytvoření ledu v zařízení může zapříčinit netěsnosti a zničení ohřívače! Místo instalace musí...
Seite 41
U zásobníků s kanály pro snímače zasuňte svisle snímače. Trubky však namontujte teprve poté, co jste namontovali tepelnou izolaci. U akumulátoru SPU-1-200 je již zabudovalo ponorné pouzdro. Tepelná izolace SPU-1-200 je z tvrdé PU-pěny doplněné snímatelnou fólií. V blízkosti izolace nepoužívejte otevřený plamen, pájecí lampu ani svařovací hořák.
Poruchy, jejich příčiny a odstranění Porucha Příčina Odstranění Netěsnost na vyrovnávacím zásobníku Netěsnost trubkových přípojek. Nově utěsnete. Příliš malý rozdíl teplot ve výměníku Nesprávné nastavení na solární regulaci. Změňte parametry. tepla solárního okruhu (zejména vypínací rozdíl teplot) Příliš malý průtok (v solárním okruhu). Odvzdušněte solární...
Seite 44
Upozorňujeme na platnosť všeobecných obchodných podmienok v aktuálnom platnom znení. Stručný opis Akumulačný zásobník typu SPU-1-200, SPU-2(-W)-500 do 1500 a SPU-2-2000 do 5000 bol vyrobený z ocele S235JR (St 37-2). Môže sa používať iba ako akumulačný zásobník na obehovú vodu v uzatvorených vykurovacích zariadeniach (pokiaľ...
Seite 45
Technické údaje SPU-1 SPU-2-W SPU-2 SPU-1 SPU-2-W / SPU-2 1000 1500 2000 3000 4000 5000 Menovitý objem zásobníka SPU-1 Ltr. SPU-2-W Ltr. 1520 SPU-2 Ltr. 1545 1950 2700 3950 4950 Hrdlo / teplomer / kanál snímačov A mm Hrdlo / teplomer / kanál snímačov B mm 1050 1135...
Seite 46
Pokyny na projektovanie Umiestnenie Akumulačný zásobník sa môže umiestniť iba v miestnosti chránenej pred mrazom, pri hroziacom mraze treba zásobník, ako aj všetky vodou naplnené armatúry a prívodné potrubia vypustiť! Tvorba ľadu v zásobníku môže spôsobiť netesnosti a viesť k zničeniu zásobníka! V mieste inštalácie musí...
Seite 47
Pri zásobníkoch s kanálmi snímačov zasuňte snímače v zvislej polohe. Pripojenie sa musí inštalovať až po montáži tepelnej izolácie. V zásobníku SPU-1-200 je už zabudované ponorné puzdro. Tepelná izolácia SPU-1-200 je z tvrdej polyuretánovej peny doplnenej snímateľnou fóliou. V blízkosti izolácie nemanipulujte s ohňom, spájkovacím plameňom alebo zváracím horákom.
Seite 48
Porucha / Príčina / Odstránenie Porucha Príčina Odstránenie Netesnosti na akumulačnom zásobníku Netesné potrubné spoje. Nanovo utesnite. Príliš nízke teplotné rozdiely v solárnom Nesprávne nastavená solárna regulácia. Zmeňte parametre (najmä vypínaciu výmenníku diferenciu). Príliš nízky prietok v sústave solárneho Odvzdušnite solárny okruh, uvoľnite výmenníka.
Skrócony opis Zasobniki buforowe typów SPU-1-200, SPU-2(-W)-500 do 1500 i SPU-2-2000 do 5000 wykonane są ze stali S235JR (St 37-2). Wewnętrzne ścianki zasobników i wymiennik ciepła (o ile występuje) nie są chronione przed korozją, ponieważ...
Dane techniczne SPU-1 SPU-2-W SPU-2 SPU-1 SPU-2-W / SPU-2 1000 1500 2000 3000 4000 5000 Pojemność zasobnika SPU-1 SPU-2-W 1520 SPU-2 1545 1950 2700 3950 4950 Przyłącze / termometr / listwa czujnikowa A mm Przyłącze / termometr / listwa czujnikowa B mm 1050 1135...
Seite 52
Wskazówki projektowe Miejsce ustawienia Zasobnik buforowy powinien być ustawiony wyłącznie w pomieszczeniu zabezpieczonym przed mrozem. W przypadku niebezpieczeństwa wystąpienia ujemnych temperatur w pomieszczeniu, należy opróżnić całą objętość zasobnika oraz elementy armatury i rurociągi przyłączeniowe, w których znajduje się woda. Zamarznięcie wody w instalacji może doprowadzić do pojawienia się nieszczelności i uszkodzenia zasobnika! Pomieszczenie, w którym przewiduje się...
Seite 53
Podłączenie rurociągów należy wykonać dopiero po założeniu izolacji cieplnej. W zasobniku SPU-1-200 jest już zamontowana tulejka zanurzeniowa. Izolacja cieplna zasobnika SPU-1-200 składa się z części zasadniczej wykonanej ze spienionego poliure- tanu (PU) w postaci twardej pianki oraz ze zdejmowanego płaszcza z folii.
Seite 54
Usterki / przyczyny / usuwanie Usterka Przyczyna Usuwanie Nieszczelność na zasobniku Nieszczelne przyłącze rurowe Zamontować nowe uszczelki buforowym Za mała różnica temperatur w Błędne nastawy regulatora instalacji solarnej Zmienić parametry regulacyjne solarnym wymienniku ciepła (szczególnie wartość różnicy tempe- ratur, wyłączającą obieg solarny) Zbyt mały przepływ po stronie instalacji solarnej Odpowietrzyć...
