PAR LED RGB
The fade time can be select by set DIP-Switch 1 to 6 to ON:
Dipswitch fadetime for
to ON one pattern
1 2,5s
2 5s
3 10s
4 20s
5 40s
6 80s
If dipswitch 1 to 6 is set to OFF the fade time for one pattern is 10:30min.
The related time of dipswitch 1 to 6 can be added:
Dipswitch 1 and 2 to ON, fade time = 2,5s + 5s = 7,5s
7.4

DMX Mode

For select "DMX Mode" set DIP-Switch 8 to OFF and at least one of dipswitch 1 to 7 to ON.
The item use 5 DMX channels for control. Dipswitch 1 to 7 sets the first channel to receive.
The value of dipswitch 1 to 7 is binary coded.
For example: You have 3 LED PAR Cans which you will controll different with DMX
1 2 3 4 5 6 7 8 Dipswitch
x
x x x x x x x
x x
x x x x x x
x x x
x x x x x
Function of DMX channels:
Channel 1 value
0 - 63
64 – 127
128 – 191
192 – 255
Channel 2 value
0 – 255
Channel 3 value
0 – 255
Channel 4 value
0 – 255
Channel 5 value
0 - 10
11 - 100
101 - 150
151 - 255
DMX Channel
ON 1. LED Par Can (DMX channel 1)
OFF
ON 2. LED Par Can (DMX channel 6)
OFF
ON 3. LED Par Can (DMX channel 11)
OFF
RGB control, CH2 = red, CH3 = green, CH4 = blue
7 color fade, CH5 = speed control
7 color change, CH5 = speed control
3 color change, CH5 = speed control
Red color 0% – 100%
Green color 0% – 100%
Blue color 0% – 100%
no function – no speed
value 11 to 100, fast speed to low speed
no function – no speed
speed controll by unit, by music or VAR
