Safety Instruction

•
Keep this device away from rain and moisture!
•
Unplug mains lead before opening the housing!
•
Never look directly into the light source (sensitive persons may suffer an epileptic shock).
•
Never leave this device running unattended.
•
Keep away children.
•
When installing the device, make sure there is no highly inflammable material within a
distance of 0.5m.
6

Overview

Back view
This picture shows the backside of the LED PAR.
DMX-Input:
In case of external DMX control, the DMX cable is connected here.
DMX-Input pin
1
2
3
DMX-Output:
Connect here the DMX cable for next unit.
DMX-Output pin
1
2
3
DIP Switch 1-8:
With this DIP switches you can chose the MODE.
Speed:
Manual speed setting.
Music / Auto
With this switch you can select Audio control or control by Speed
Signal
Ground
Signal "-"
Signal "+"
Signal
Ground
Signal "-"
Signal "+"
