PAR LED RGB
7

Function Selection

7.1

Auto Change

For select "Auto Change" set all DIP-Switch to OFF.
1 2 3 4 5 6 7 8
x x x x x x x x OFF
For music control set switch to "Music".
For control by VAR set switch to "Auto".
7.2

Manual Mode

For select "Manual Mode" set DIP-Switch 7 and 8 ON.
1 2 3 4 5 6 7 8
x x ON
x x x x x x
For select brightness set dipswitch 1 to 6 to ON:
1 2 3 4 5 6 7 8
red green blue
0% 0% 0%
x x ON
x x x x x x
25% 25% 25%
x x x x x ON
x x x
50% 50% 50%
x x x x x ON
x x x
100% 100% 100%
x x x x x x x x ON
7.3

Auto Fade

For select "Auto Fade" set DIP-Switch 7 to OFF and 8 to ON.
1 2 3 4 5 6 7 8
x ON
x x x x x x x
ON
OFF
OFF
OFF
OFF
OFF
OFF
8
