1. Referring to the compatibility list of makes and models, select the
correct charging-cable adapter tip for your notebook.
Be aware that notebook manufacturers frequently change the tip
design so you may find that the recommended adapter tip doesn't fit.
If so, or your notebook make isn't listed, try all the adapter tips: first
make sure your notebook is switched off and the plug is disconnected
from the mains; following that, test each of the adapter tips in turn by
plugging them into your notebook's power socket.
The adapter tip should insert into the socket with minimal effort and
2. If the integrated power tip is unsuitable for your notebook, connect
the appropriate adapter tip to the power adapter's charging cable.
3. Set the required output voltage using the slider on the power
adapter. Please refer to the notebook label, the manual or the original
power adapter for the correct voltage level.
NEVER select a higher voltage level. Furthermore, make sure the
notebook's power requirements do not exceed the maximum voltage
output of the power adapter (90 Watts). If you cannot set the required
voltage level precisely, set the next lowest voltage-output level.
4. Now plug the charging cable, with the correct adapter tip fitted, into
5. Using the power cable, plug the power adapter into an AC outlet
(100-240V, 50/60Hz). The LED on the power adapter will glow and the
FOR ADDITIONAL USER GUIDE LANGUAGES,
PLEASE VISIT www.speedlink.com/support
EN
remain securely in place.
the notebook's power socket.
notebook will be powered.
