Telefunken TFGS45SI10A+++ Gebrauchsanweisung Seite 70

Inner Light Option:
11
2 4
1 3
Machine must be ON position during activation and deactivation of inner light modes.
Open or close position of the door is not important.
How to change from "ECO MODE" to "NORMAL MODE" for Inner Light option
First energize the machine via main switch (if it is in OFF position).
Press "Fast" (2) and "Silent" (3)
"IL0" will be shown in the display for 2 seconds to show the "Normal Mode" is selected for
inner light option.
After "Normal Mode" is selected, the inner light will be ON as long as the machine is energized
and machine door is open.
How to change from "NORMAL MODE" to "ECO MODE" for Inner Light option
First energize the machine via main switch (if it is in OFF position).
Press "Fast" (2) and "Silent" (3)
"IL: 01" will be shown in the digit display for 2 seconds to show the "Eco Mode" is selected for
inner light option.
Also inner light turns OFF and ON again (blinks momentarily) to show this selection is activated.
*After "Eco Mode" is selected, the inner light will be ON for 4min after machine door is opened
and then turns OFF.
If any user intervention occurs such as pressing buttons, Eco Mode cycle starts from beginning
(inner light is ON for 4min and then becomes OFF again)
Note: Factory setting for inner light is set to ''IL: 01''.
5
buttons simultaneously for 3 seconds.
buttons simultaneously for 3 seconds.
EN-29
9
10
6 7
8
