OVERVIEW
AUDIO SOURCES
You can play music from the following audio sources:
• FM Radio
• DAB Radio ( available only for Model S DAB+ )
• Mobile phone or computer via Bluetooth
• Other devices with a Line-In cable
DAB Radio
FM Radio
Bluetooth Line-In
GETTING STARTED
1. Remove the protection paper from the remote
control battery compartment.
2. Connect the enclosed external telescopic antenna.
Connect the AC power cable to the AC power plug
on the back panel.
Line-In Antenna AC power
REMOTE CONTROl
Power On / Off
Volume control
Bass control
Treble control
Set time
Set alarm time
Alarm On / Off
Select FM, DAB,
Bluetooth, Line - In
DAB & FM frequency, alarm
Mute, Mono / Stereo ( FM )
DAB / FM presets
TOUCH PANEl
Model S
Power On / Off
Volume control
Bluetooth
FM
Line - In
DAB & FM frequency, alarm
Mute
Set time
Set alarm time
Alarm On / Off
Model S DAB+
Power On / Off
Volume control
Bluetooth
FM
DAB
Line - In
DAB / FM frequency, alarm
Set time
Set alarm time
Alarm On / Off
2
USING THE MODEl S
SElECTING THE AUDIO SOURCE
The audio source can either be selected with remote
control key MODE or the touch panel keys on the
device ( FM, DAB,
and ).
FM RADIO
1. Touch MODE on the remote control until the
display shows an FM frequency or touch FM on
the device.
2. Select a FM station with and :
• Use a single touch: change frequency by 0.1 MHz.
• Hold down for a short time: automatically search
for another station.
Storing a radio station with the presets
1. Select your favorite radio station using the or
key on the remote control or on the touch panel.
2. Select one of the 6 preset keys on the remote
control, and keep pressing it until the correspond-
ing letter on the display starts blinking. The station
has now been stored.
Using the presets
Press one of the preset keys to recall a radio station.
DAB / DAB+ ( MODEl S DAB+ ONlY )
1. Touch MODE on the remote control until the dis-
play shows DAB or touch DAB on the device.
2. Select a DAB station with and .
Model S DAB+ is compatible with DAB, DAB+,
DMR and DMB.
Scan function
When using your Model S for the first time, the radio
needs to find available radio stations in your region
( done by using the "Scan" function ). After a scan, the
stations will be automatically stored.
• Within 5 seconds of entering DAB mode, hold down
the button until "Scan" displays.
"Scan" is also needed after traveling to a new location
with different radio stations, or when you move
the radio to a different room where there is different
radio reception.
BlUETOOTH
Mobile phones and computers with Bluetooth can
connect to the Model S and play music. The mobile
phone or computer must support Bluetooth A2DP.
Initial Setup ( "Pairing" ) With iPhone ®
1. Touch the MODE key until the display shows
"Blue". Wait for 20 seconds until the display shows a
blinking "P" or "Pairing".
®
2. Select "Settings" on your iPhone . Select "General
/ Bluetooth". Turn on Bluetooth. New Bluetooth
devices are detected automatically. After a few
seconds "GENEVA S ( Not Paired )" will appear.
3. Select "GENEVA S". The phone is now connecting
( "P" or "Pairing" ) to the Model S.
4. If the phone asks for a PIN: enter "0000"( four zeros ).
®
5. Now you can play music on an iPhone and listen
to it on the Model S.
English
Playing Music
Most phones connect automatically to the Model S
after the initial setup ( "Pairing" ).
1. Touch the MODE key on the remote control until the
display shows "Blue". When Model S connects, the
display shows "C" or "Connect" for a few seconds.
2. Play music on the mobile phone, music will start
playing on Model S automatically.
Pairing guides for other devices and mobile phones
Go to www.genevalab.com and select "Support."
Status information on the display
S / Search: Searching previously paired devices.
C / Connect: Connection successful.
P / Pairing: If Model S did not make a successful
connection within 20 seconds, Model S will go into
the pairing mode for 2 minutes.
lINE - IN
1. Connect one end of a Line - In cable to the Line - In
plug on the back of Model S. Then connect the
other end to the audio device ( headphone or Line-
Out plug ).
2. Touch MODE until the display shows "Line" or .
AlARM
Setting the alarm
1. Touch , "A" starts blinking on the display.
2. Set the desired alarm time using and .
3. Touch again to save the alarm time. "A" indi-
cates alarm is now on.
4. Touch to turn Model S off.
Turning the alarm On and Off
1. Turn on Model S, then touch to toggle the alarm.
"A" ( Model S ) or "ON" ( Model S DAB+ ) indicates
that the alarm is on.
2. If the device is off, the alarm can also be toggled by
touching any key on the touch panel.
Muting the alarm
Touch any key on the touch panel to mute the alarm.
The alarm will automatically turn off after 2 minutes if
no key on the touch panel is touched.
Selecting the alarm sound
There are two alarm sounds: radio and a beeping
sound. If you set the alarm and the current mode is
FM or DAB, the FM or DAB radio will play when the
alarm goes off. Otherwise the beeping sound is used.
Setting the clock manually
1. Touch : "C" starts blinking on the display.
2. Use and to set the time.
3. Touch to complete the procedure.
Model S DAB+ sets the time automatically.
Every time Model S DAB+ gets a valid time signal from
a DAB station, it will set the time automatically. If there
are no DAB stations, the time has to be set manually.
Model S ( US Version ): AM / PM Display
The dot to the right of the minute digits indicates AM
or PM: Off = AM, On = PM.
3
