User Manual Prexiso XL2

1.1 Features
4
1 Keypad
2 Rubber
3 Locking knob
4 Laser window
5 1/4'' nut
6 Battery box cover
Use 3 pieces of AA size 1.5 V alkaline or
rechargeable batteries
7 Soft bag
8 L-shaped mount
783114 en
1
2
3
5
6

1.2 Insert and replace batteries

Refer to the sketch, open up its bottom battery cover, and
insert the batteries in accordance with the polarities. Close
up the cover till the click of closing is heard.
When battery is low with voltage, laser beams will get dim,
7
batteries should be timely replaced.
Use alkaline or rechargeable batteries only!
8
When the instrument is not used over a long period of
time, please remove the batteries to avoid corrosion of the
batteries.
1.3 Operation
First, switch the locking mechanism to its unlock position,
the horizontal and vertical beams are lit up at the same
time
