The already installed lamp means the fixture is immediately ready for
use. Therefore you do not need to install the lamp first.
General Installation Guideline
During installation, make sure that all components are easily
accessible for replacement.
Important!
100-230V wall fixtures may only be installed by a certified electrician.
Step 1
Switch off the electricity circuit to which the fixture will be connected.
Use a voltage meter to check if power has been eliminated from elec-
trical wires that will be used to connect the fixture.
Step 2
Remove the Torx screw (A). (Fig. 5a) Remove the cap of the fixture by
turning in the direction of the arrow. (Fig. 5b)
Step 3
Pass the electricity wires through the hole and attach the back part
of the fixture to the wall using the accompanying screws (B). (Fig. 6)
When doing so, remove the white connecting blocks if necessary (Fig.
6)
Important!
The accompanying screws are not suitable for connecting to an elec-
trical cabinet.
Step 4
Place the cap of the fixture on the hooks in the back panel. Assemble
the power wires. (Fig. 7)
Step 5
Re-attach the fixture to the assembly plate. The hooks can remain in
place. Tighten the Torx screw. Switch on the electrical circuit.
General maintenance advice
We advise you to clean the fixture at least once a year using a clean
cloth and warm water. During cleaning activities, switch off the elec-
tricity circuit to which the fixture is connected.
