WARNING!
■ INGESTION HAZARD: This
product contains a button cell or
coin battery.
■ DEATH or serious injury can occur
if ingested.
■ A swallowed button cell or
coin battery can cause Internal
Chemical Burns in as little as 2
hours.
■ KEEP new and used batteries
OUT OF REACH of CHILDREN.
■ SEEK immediate medical
attention if a battery is suspected
to be swallowed or inserted inside
any part of the body.

Technical Data

Product type
Coin cell battery
Radio technology
Frequency range
Bluetooth,
maximum output
power
Working temperature
Storage temperature
Overview (see figure A)
1 Bluetooth module* (not included for
VCE/VC RC )
2 Bluetooth module button
3 Bluetooth module indicator
4 Remote control
5 Remote control indicator
6 Start/stop button
7 Suction power adjustment buttons
8 32 mm Fastening strap – compatible
with 32 mm hose diameter
9 Universal fastening strap – compatible
with multiple hose sizes
8
VCE/VC RC Set
VCE/VC RC
model CR2450
V 3
Bluetooth 5.0
MHz 2402-2480
dBm +10dB
-10~40°C
-20~50°C
Operation
This attachment is compatible with FLEX
vacuum cleaners listed as below and allows
wireless operation via remote control. Use the
remote control to start and stop the machine
manually or automatically, and to adjust the
suction power as needed.
Please refer to the individual machine manual
for detailed instructions, or contact our sales
support for more information on compatible
machines.
Model number
NOTE
Make sure the remote control is paired
and connected correctly, and that the coin
cell battery is sufficiently charged to work
properly.
Installing/Replacing the coin cell
battery (see figure B)
NOTE
Once pairing has been successfully
completed, the device remains paired even
after the coin cell battery is replaced.
■ Rotate the battery cover (B-1)
counterclockwise to unlock position.
■ Remove the cover and the old battery if
available.
■ Observing the correct polarity (+ and -),
push the specified battery CR2450 (B-2)
into the compartment.
■ Install the cover and rotate it clockwise to
the lock position.
Installing the Bluetooth module
(see figure C)
■ Always unplug the corded machine from
the mains socket or remove the battery
pack from the cordless machine before
installing the Bluetooth module.
■ Plug the Bluetooth module (1) into the
Bluetooth module port (C-1) on the
machine.
■ Tighten both screws (C-2) to secure the
Bluetooth module.
Remote control pairing (see
figure D1-D2)
■ Press and hold the Bluetooth module
button (2) for approximately 3 seconds
VCE/VC RC (Set)
VC 9 L MC 18 RC
