5 OPERATING PROCEDURES

1 - Press the die cut area on the box (1).
Extract the strap (2). Extract the pinch tube
and the union from the box. Insert the
union in its housing (3). Fix the union in its
housing by the strap (4) (see figure 1).
1
3
figure 1
2 - Insert the box into the dispenser taking
care to push it to the end (see figure 2).
figure 2
3 - Push the faucet lever and insert the pinch
tube in its housing (see figure 3).
figure 3
Delta
4 - Cut the pinch tube as near as possible to
its closed end (see figure 4).
2
4

6 HELPFUL HINTS

1 - To shorten product cooling down time and
increase productivity, it is advisable to pre-
c h i l l t h e p r o d u c t t o b e u s e d i n t h e
dispenser.
2 - How to reset beverage temperature:to
reset beverage temperature please apply
to a technician.
The proper temperature is preset at the
factory.
3 - It is poss ible to lock th e door of th e
dispenser (see figure 5).
4 - It is possible to set the proper drink outflow
by turning the nut behind the faucet button
OPERA 210
figure 4
figure 5
7
