Verfügbare Sprachen
Verfügbare Sprachen
•
Never charge a Li-Po battery which is inflated by overheating, crashing and overloading
•
Check accurate to see whether the battery is damaged after a fall. Damaged batteries must be
disposed of
•
Install the battery with correct
polarity
•
Charge the Li-Po battery only with
the standard charger
•
Should the Li-Po battery during the
charging process burn please do not extinguish with water. Please use sand for instance
•
Charge the battery only under the supervision of adults. Please pay attention to a possible
overheating of the battery
•
Avoid short circuit at terminals of battery
•
Please take care of sharp or edged objects which could damage the Li-Po battery
•
If the Li-Po battery suffers an impact, please store the battery for the next 30 minutes at a
safety location. Please make sure if the Li-Po battery blows up or overheated
•
Please do not try to manipulate, modify or to repair a Li-Po battery
2. 2.4 GHz Remote
2A On / Off Switch
2B 360 ° flips
2C CF Mode
2D& Gas Left / Right rotation
2E Photo function / video function
2F forward / back / left / right
2G fast / slow
2H Display
2Ikeep the altitude
2J Trim rotation
2K Trim Left / Right
2L Trim Before/Back
To swap the position of the two sticks and
switch the mode, please follow the steps
below.
Press the Left / Right Trim to the right and
hold it. Then press the on / off switch on the
remote control. Now you have the functions
of the two control sticks reversed. Which
mode you are flying, you can also see on the
display position 13.
CF Mode: Make sure that the copter is in front of you and facing forward. Bind now the device. Press
the "Headless" mode in order to get there. You will hear a sound and the lights on Copter begin
flashing. Please press this button again to exit the headless mode.
4.Binding of radio transmitter and receiver
2.1 Left / Right Trim
2.2 fore / aft trim
2.3 Rotation trim
2.4 Gas
2.5 Before
2.6 Back
2.7Left Flight
2.8 Right Flight
2.9 Links yaw
2.10 right yaw
2.11 Fast / Slow
2.12 Back Battery Status
4A
4B
4C
2.13 Mode display
2.14 Signal display
The spacecraft on a flat position, the Lipo-Battery
icon in accordiance with direction pushing people
electric socket to position. Body LED flashing
lights at this time not to move the body, makes
the remote controller reads the neutral point of
frequency and gyroscope(~20sec)
Open the power supply control switch, remote
control issued a bit of noise, a few seconds after
the end of the fuselage LED noise, at the same
time often bright, completes to the code
Remove the flight vehicle battery safely at the
conclusion of flight. This should be made into a
