ENGLISH
Montageanleitung
QUICK GUIDE
Assembly instructions
Instructions de mont age
Instruzioni di mont aggio
Montage Handleidig
Instrucciones de mont aje
VIDEO
ø?
ø 16 mm
1
ø 8 mm
ø 10 mm
2
3
ø 16 mm
12
ø 8 mm
ø 10 mm
1
ø 16 mm
CLOSE
ø 8 mm
ø 10 mm
2
2
4
OPEN
1
CLOSE
1

CYCLE

Using the adapter included, the Hard Back Pro holder
QMR hook can be adapted to different rack tube diame-
CLOSE
ters (see Hard Back Pro).
To assemble, release the QMR hook knurl catches and
move them into position. Tighten the knurl catches
again to fi x the hook in position (1). Pull the bag's hand-
le to open the QMR hooks. Next, hang the bag on the
rack and press it to make the QMR hooks automatically
click into place (2).
4
3 Now hook the elastic band with the hook to the rack
and pull it tight with the slide adjustment buckle at the
other end (3).
OPEN
3
