CE MARKING

The plate bearing the CE mark (Fig.15) gives
the main characteristics and information for
the identification of the turf cutter.
• Manufacturer's details
• Machine model
• Serial number
• Year of construction
• Capacity in kW
• Weight in kg
The above information must not be altered or
modified in any way. It is up to the user to keep
the plate clean, legible and in good condition.
The position of the CE plate on the machine is
shown in the figure below

DIAGNOSTICA

The following table illustrates some problems which may arise during operation.
FAULT
Belt slips
Machine vibrates
excessively
Engine overloads
during work
operations
48
CAUSE
1. Belt tension inadequate
2. Too great a working depth
3. Belt worn
1. Belt damaged
2. Blade bent or broken
1. Engine speed too low.
2. Blade worn
3. Forward speed too high
4. Too great a working depth
MEASURES TO BE TAKEN
1. Adjust the belt tension
2. Reduce the working
depth
3. Replace belt
1. Replace belt
2. Replace blade
1. Accelerate to maximum
2. Replace blade
3. Decrease the forward
speed
4. Reduce the working
depth
EN
Figure 15
