axing basic-line SVS 4-01 Betriebsanleitung Seite 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
EU Declaration of Conformity
Hereby AXING AG declares that the CE marked products comply with the
valid EU guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Technical improvements, changes in design, printing and other errors reserved.
Page 1 of 2 | AXING-BA_SVS-4-01_20260217.pdf | 2026-02-17
Technical data:
Type
EMC
Frequency range
Gain
Equalization
Output
Max. output level TERR
(3rd order, EN 50083-3, 60 dB KMA)
Max. output level SAT
(3rd order SAT, EN 50083-3, 35 dB KMA)
Noise figure
RF connectors
Type
General
DC power pass
Remote voltage
Current consumption
Max. through-current
Dimensions (W × H × D) appr.
Weight
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
www.axing.com info@axing.com
SVS 4-01
according to EN 50083-2, class A
47 ... 862 MHz | 950 ... 2400 MHz
12 dB | 13 ... 17 dB
0 dB | 4 dB
102 dBµV
SVS 4-01
113 dBµV
6 dB
basic-line
F-female
SAT inline amplifier
yes
14 ... 18 VDC
45 mA ± 5 mA
Operation instructions
500 mA
85 × 26 × 20 mm
0.050 kg
