LIGHTMAX Vector Spot 150 Bedienungsanleitung Seite 10

10CH 12CH
CH1 CH1
CH2 CH2
CH3 CH3
CH4 CH4
CH5 CH5
CH6 CH6
CH7 CH7
10
DMX Definition Table
14CH 16CH Function
CH1 CH1 Pan
CH2 CH2 Pan fine
CH3 CH3 Tilt
CH4 CH4 Tilt fine
CH5 CH5 X,Y Speed
CH6 CH6 LED Dimmer
CH7 CH7 LED Strobe
CH8 CH8 7 color + white
CH9 CH9 8 static Gobos + white
Channel Value Discription
000-255 0-540°
000-255 Pan fine
000-255 0-270°
000-255 Tilt fine
000-255 From fast to slow
000-255 From dark to bright
000-007 Turn on
008-250 Strobe from slow to fast
251-255 Turn on
000-015 White Lighting
016-031 Color 1
032-047 Color 2
048-063 Color 3
064-079 Color 4
080-095 Color 5
096-111 Color 6
112-127 Color 7
128-191 CW from slow to fast
192-255 CCW from slow to fast
000-006 Open
007-013 Gobo 1
014-020 Gobo 2
021-027 Gobo 3
028-034 Gobo 4
035-041 Gobo 5
042-048 Gobo 6
049-055 Gobo 7
056-063 Gobo 8
064-070 Gobo 8 shake speed
from slow to fast
071-077 Gobo 7 shake speed
from slow to fast
078-084 Gobo 6 shake speed
from slow to fast
085-091 Gobo 5 shake speed
from slow to fast
092-098 Gobo 4 shake speed
from slow to fast
